RS-400LA Heat Shrink Packing Machine
It is widely used in food, pharmaceutical, cosmetics, printing, hardware, and other industry.
Share to:
Product Overview
It is a fully automatic shrink packaging machine including sleeve sealer and shrink tunnel which can feed products, collating, seal and cut film and shrink film bag automatically.

Drawings:

Characteristics

1. RS-400LA+RSD-450C is a fully automatic shrink packaging machine including L sealer and shrink tunnel which can feed products, seal and cut film and shrink film bag automatically. It is widely used in food, pharmaceutical, stationary, toy, auto parts, cosmetics, printing, hardware, electrical appliances and other industry.

2. Special durable alloyed sealing knife with anti-stick Teflon coats makes sealing strong and has better performance of heat conduction.

3. Only adjust packing width and height by hand wheels without changing any molds and parts when packing size changes. Packing length can be detected by the sensor automatically.

4. Different products with different sizes can be packed together as promotional package.

5. Adopt Omron brand parts such as temperature controller, timer, relay, switch, and sensor.

6. A pair of photoelectric switch in vertical for thin products.

7. Optional closing conveyor for small products.

8. Optional sensor for transparent products.

Application
It is widely used in food, pharmaceutical, cosmetics, printing, hardware, and other industry.


Technical Parameter
SEALING TYPE L SEALING
POWER SUPPLY 380V/50-60HZ/3PHASE
MAX PRODUCT SIZE W≤200MM W+H≤250MM L+H≤330MM
MAX PACKING CAPACITY 15-45 PACKS PER MINUTE
FILM TYPE POLYETHYLENE (PE) / POF FILM
MAX FILM SIZE 380 (WIDTH) X 280MM (OUTER DIAMETER)
POWER CONSUMPTION 6KW
TUNNEL OVEN SIZE 1200MM(L) X 300(W) X 165(H) MM
TUNNEL CONVEYOR SPEED VARIABLE, CONTROLLED BY FREQUENCY CONVERTER
TUNNEL CONVEYOR CHAINS WITH SILICON COATED RODS OR STEEL MESH CONVEYOR
WORKING HEIGHT 780-850MM
AIR PRESSURE 0.5MPA (5 BAR)
SEALING KNIFE SAW TEETH CUTTING KNIFE WITH ANTI-STICK TEFLON COATS
OPERATION PANEL SIEMENS COLORFUL TOUCH SCREEN, OMRON TEMPERATURE CONTROLLER
MACHINE MATERIAL CARBON STEEL
MACHINE WEIGHT 390KG
MACHINE DIMENSIONS 1600 X 770 X 1450MM
