RS-420F Powder Packing Machine
For packing powder such as milk powder, coffee powder, seasoning powder, spice powder ect. Intelligent temperature controller is used, correct temperature control, ensure nice, smooth seal.
Share to:
Product Overview
For packing powder such as milk powder, coffee powder, seasoning powder, spice powder ect.
Characteristics
With imported PLC control system, simple-operating, visual touch screw.
Servo film feeding system, correct register, sealing and cutting positions adopt automatic correction device, high automation.
Intelligent temperature controller is used, correct temperature control, ensure nice, smooth seal.
Perfect automatic alarming protective function, reduce the consumption up to the lowest.
When the machine is combined with metering equipments, full packaging process including automatic feeding, metering, bag filling, date printing and automatic counting is completed.
Type of bag making: according to customer's demand, the machine can produce pillow bags, punched hanging bags.
Technical Parameter
| Model | RSD-420 | RSD-520 | RSD-730 |
| Range of Measurement | 1-1500 g | 1-3000 g | 200-5000g |
| Speed | 30-80 bags/min | 30-80 bags/min | 30-60 bags/min |
| Bag Size | W: 70-180 mm | W: 80-260 mm | W: 80-350 mm |
| L: 50-280 mm | L: 50-340 mm | L: 50-460 mm | |
| Max outer diameter of reel | 400 | 400 | 500 |
| Air source consumption | 0.6 MPa 0.3m³/min | 0.6 MPa 0.3m³/min | 0.6 MPa 0.3m³/min |
| Power | 3 Kw | 3 Kw | 3 Kw |
| Weight | 700 kg | 800 kg | 1000 kg |
| Dimension(LxWxH) | 1380x1150x1500 mm | 1480x1250x1600 mm | 1420x1530x1830 mm |
