This machine is mainly used for powder filling and sealing in the doypack or pouch. The bag with or without zipper lock is all avaiable.
Share to:
Product Overview
This automatic packing machine unit is specialized in powders, paste such as milk powder, coffee powder, flour and other powders. After the accurate measurement based on the specified parameters with measurement equipment, convey to the horizontal pre-made packing machine,the horizontal packing machine will do filling, sealing and output packages.
Characteristics


1.Easy to operate, adopt advanced PLC from Germany Siemens, mate with touch screen and electric control system, the man-machine interface is friendly.

2.Automatic checking function: no pouch or pouch open error, no filling and sealing. The bag can be used again, avoid wasting packing materials and raw materials.

3.Safety device: machine stop at abnormal air pressure, heater disconnection alarm.

4.Powder hopper with mixing function and cover, avoided the flying dust.

5.The machine is easy to clean, easy maintenance.

6.The part where touch to the material is made of stainless steel

Application

Samples:




Technical Parameter



Parameter:

 Applicable film

 PET/AL/PE, PET/PE, NY/PE, NY/AL/PE

 Packing products

 Powders

 Packaging speed

 30-60 Bag/Min

 Bag width

 90mm210mm

 Bag width

 100mm320mm

 Max volume

 500ml

 Feeding Nozzle

 2

 Total power

 5KW

 Electric source

 380V 50/60HZ

 G.W.

 1150 kg

 Size

 2900mm×1050mm×1300mm
