DPB-80 Automatic Blister Packing Machine
This machine applies : capsules, tablets, sugar-coated, capsules, and other special shaped medical device, light industry and food, electronic components sealed blister packaging.
Share to:
Product Overview
This machine applies : capsules, tablets, sugar-coated, capsules, and other special shaped medical device, light industry and food, electronic components sealed blister packaging. Photoelectric control systems, PVC, PTP, tropical aluminum packaging automatic feed, scrap automatic admission Device, to ensure the long-synchronous multi-position stability.
Characteristics


1. With high power drive system, the main axle was drove by the row chain, avoided the error and noise from other gear drives.


2. With imported control system, it can be customization according to your requirements.


3. Finish the incomplete filling once starved feeding, and rejection of unqualified finished products.


4. The whole machine with segment combination, which is fast assembling and convenient transportation.


5. With photoelectric control system.


6. The photoelectric detection system is optional, with imported step motor.



Application


Video:


Technical Parameter

Model

DPB-80

Punch Frequency

10-35 times/min

Production Capacity

2400 edition/hour

Max. Formed Area and Depth(mm)

80x110x26

Travel Range (mm)

20-70

Standard Plate (mm)

80x57

Air Pressure (m3/min)

0.6-0.8

Total Power

380V/220V 50Hz 3.2KW

Main Motor Power

0.75 KW

PVC Hard Pieces (mm)

0.15-0.5 x 80

PTP Aluminum Foil (mm)

0.02-0.035 x 80

Dialysis Paper (mm)

50-100g x 80

Mold Cooling

Water cycle

Overall Dimensions (mm)

1600x600x1100

Weight (kg)

450
