Case Packer
According to the customer"s arrangement requirements, the products are automatically arranged in layers and groups, and the carton is automatically opened and positioned before filling, and the products are loaded into the carton by top load, side push, robot ect.
Share to:
Product Overview
The biggest feature of the machine is that it integrates unpacking, packing and sealing, which is also called three-in-one packing machine. According to the customer's arrangement requirements, the products are automatically arranged in layers and groups, and the carton is automatically opened and positioned before filling, and the products are loaded into the carton by top load, side push, robot ect. It can meet the requirements of various specifications and realize automatic unpacking and sealing. The machine can be sealed by tape or hot melt adhesive according to customer requirements. Adopt the PLC control, the touch screen can show the running status and error alarm, such as no material alarm, door open alarm,other faults alarm. Packing products are widely used in tissue paper, wet tissue paper, food, medicine, cosmetics, health products, bottle, can,hardware and other various products.
Characteristics
1. Automatic finished the carton opening, bag feeding and carton sealing.
2. The size of carton can be adjusted accordingly to the products.
3. The every part can be worked separately, and all the data can be adjusted in the touch screen.
4. Automatic detection of the carton quality and feeding quantity. If there’s any faults, the machine will be stopped and start the safety protection. The details will be showed in the touch screen.
5. The feeding is smooth match with different kind of products.
6. No damage for the cartons and products.
Application
Samples:


Technical Parameter

Overall Dimension

L2100×W1300×H1900mm

Capacity

50 - 150 bags/minute

Feeding Products

POUCHES

Power

AC220V 0.4Kw

Air Supply

0.5~0.6Mpa(5~6Kg/cm2

Air Consumption

350L/ min

New Weight

1200 kg

Carton Size (LxWxH)

Min.: 200x150x100

Max.: 600x500x350
