RS-60 Tube Filling And Sealing Machine
Applies to: plastic composite pipe and plastic composite pipeOptional device: External system Chiller, Mezzanine barrel insulation device, Barrel internal mixing device, Automatic control feeding device (pump), Finished tube output conveyor
Share to:
Product Overview
This tube fillng and sealing machine is high technical equipment and integrating GMP requirement, with features of rational structure,complete function,easy operation, accurate filling, stable running, also low noise.It adopts with PLC controller, automatically operating from liquid or high velocity material filling till batch number printing(including manufacture date).It's an ideal equipment for ALU tube, plastic tube and multiple tube filling and sealing in cosmetic,pharmacy,foodstuff,adhesives etc.

u Features

1. The transmission part of the platform or less closed, safe, reliable, non-polluting;

2. Filling and sealing portion is mounted on the platform within no more than half an enclosed frame static visual cover, easy to observe, easy operation and maintenance;

3. PLC control, man-machine dialogue interfaces;

4. Distant dial to cam driven, high speed, high precision;

5. Inclined tube compartment, the tube body with a vacuum suction device to ensure accurate automatic tube into the tube holder;

6. Photoelectric standard workstation, with high precision probes, stepper motor control hose pattern in the correct position;

7. Filling the mouth with a blanking mechanism to ensure that the filling quality;

8. No controls are not filling;

9. Sealing use (Leister hot air gun) end of the tube internal heating, cooling cooling device external configuration;

10. Typing the code word workstation automatically print at the position on the technical requirements;

11. Plastic robot hose tail cut at right angles or rounded for selection;

Applies to: plastic composite pipe and plastic composite pipe
Chinese Tube Filling And Sealing Machine Factory Price
Technical Parameter
 Item Specification
 Suitable For Plastic Composite Pipe
 Operating Speed 60/min (max)
 Filling Volume 5-250 ml
 Filling accuracy ≤ ± 1%
 Suitable hose length 50-210mm
 Suitable hose diameter Φ10-50mm
 Feeding tube system Inclined entire column feeding tube positions
