NF-80A Automatic Tube Filling & Sealing Machine
The transmission part of the platform or less closed, safe, reliable, non-polluting; Filling and sealing portion is mounted on the platform within no more than half an enclosed frame static visual cover, easy to observe, easy operation and maintenance
Share to:
Product Overview

Configuration list:

CONFIGURATION STANDARD

TECHNICAL PARAMETERS

REMARKS

● Infrastructure

Main Machine Landing Area

3m2



Working Area

15 m2



Water Chiller Landing Area

1 m2



Working Area

4 m2



Whole Machine

2.5X1.2X2.4M



Integrated Structure

Union mode



Weight

1200Kg



● Machine case body

Case Body Material

304



Opening Mode of Safety Guard

Handle Door



Safety Guard Material

Organic Glass



Frame Below Platform

Stainless Steel



Case Body Shape

Square-shape



● Power, Main Motor etc.

Power Supply

50Hz/380V 3P



Main Motor

1.5KW



Hot Air Generator

3KW



Jacket barrel heating power

2 KW

Extra Cost

Jacket barrel blending power

0.18 KW

Extra Cost

● Production Capacity

Operation Speed

50-75/min/max

Filling Range

Plastic/laminated tube 3-250ml

Suitable Tube Length

210mm

Suitable Tube Diameter

12.5-50mm

● Suitable Packing Material & Other Devices

Suitable Packing Material

Aluminum-plastic composite tube and Plastic composite tube

Obliquely Hanging Lining-up Tube Storehouse

Speed Adjustable

Material contacting with filling material

316L Stainless Steel

Jacket layer hopper device

Temp. Setting according to material and filling demand

Extra Cost

Jacket layer stirring device

In case of no material mixing, it remains fixed in hopper

Extra Cost

Auto stamping device

Single side or double sides printing at the end of seal tube.

Characteristics
1. The transmission part of the platform or less closed, safe, reliable, non-polluting;
2. Filling and sealing portion is mounted on the platform within no more than half an enclosed frame static visual cover, easy to observe, easy operation and maintenance;
3. PLC control, man-machine dialogue interfaces;
4. Distant dial to cam driven, high speed, high precision;
5. Inclined tube compartment, the tube body with a vacuum suction device to ensure accurate automatic tube into the tube holder;
6. Photoelectric standard workstation, with high precision probes, stepper motor control hose pattern in the correct position;
7. Filling the mouth with a blanking mechanism to ensure that the filling quality;
8. No controls are not filling;
9. Sealing use (Leister hot air gun) end of the tube internal heating, cooling cooling device external configuration;
10. Typing the code word workstation automatically print at the position on the technical requirements;
11. Plastic robot hose tail cut at right angles or rounded for selection;
12,. Fault Baojing, ductless alarm, the door opened down, overload shutdown;
13. Stop counting and quantitative
Application
Applies to: plastic composite pipe and plastic composite pipe


Sample:


Technical Parameter
● Suitable for: plastic composite pipe and plastic composite pipe
● operating speed: 80/min (max)
● Filling volume: 5-250ml
● Filling accuracy: ≤ ± 1%
● suitable hose length: 50-210mm
● suitable for hose diameter: Φ10-50mm
● feeding tube system: Inclined entire column feeding tube positions
● Optional: external system Chiller
● Optional: Mezzanine barrel insulation device
● Optional: barrel internal mixing device
● Optional: automatic control feeding device (pump)
● Optional: finished tube output conveyor
