Liquid And Ketchup Packing Machine
Application: liquid products, like honey,ketchup, wine, water, shampoo, cream, detergent liquid, chili sauce, milk, cooking oil, juice, cosmetic liquid, yoghurt, wasabi, jelly etc
Share to:
Product Overview
Small Sachet Vertical Liquid & Paste Packing Machine is suitable for pharmaceutical packaging, food, daily chemical industry such as liquid. For soy sauce, peanut oil, vinegar, salad oil, cough syrup and other materials for packaging.
Characteristics
1. With the function auto filling, measuring, bag forming, code printing, sealing and cutting.
2. With intelligent photoelectric controller system.
3. Machine body full of 304 stainless steel.
4. High accuracy control.
5. Sachet sealing type can choose from 3-side or 4-side seal or central seal according to customer needs.
6. Ribbon printer can print 1 - 3 lines letter, date of produce and batch number.
7. The Bag Former: The bag width is different , the former is different
8. The Bag Length :It can be adjusted and set on the Operate Interface.
Technical Parameter
| Model | RS-100Y | ||
| Bag Sealing Type | 3 side, 4 side or back side seal | ||
| Method of Measurement | Needle Valve( or Piston Pump) | ||
| Range of Measurement | 1-100 ml | ||
| Speed | 40-60 bag/min (according to the volume of each sachet) | ||
| Bag Size | W:40-180 L:30-140mm | ||
| Total Power | 1.5 Kw | ||
| Voltage | 380V or 220V | ||
| Weight | 300Kg | ||
| Dimension | 900x800x1700mm | ||
