2. Double frequency converter controller, length of package will cut immediately once setting.
3. It adopts imported electric appliance. Touch man-machine interface,convenient parameter setting.
4. Self-checking function, troubles can be read easily.
5. High sensor photoelectric color chart tracking, make the cutting position more correctly.
6. Independent temperature PID controlling suitable for various materials of packing membrane.
7. Position stop function, no adhesive and no waste of membrane.
8. Clean rotation system, more reliable operation and more convenient maintenance.
9. All the controlling operates by the software, convenience for function adjustment and technical up grading.
|
Model |
PW-300 |
PW-450 |
Reciprocating | |
|
Finished package size(mm) |
Length |
40～500mm |
65～190mm |
|
|
Width |
30～110mm |
30～170mm |
| |
|
Height |
5～40mm |
5～80mm |
| |
|
Vertical and cross sealing strength(Nuton/mm²) |
＞15N/mm² |
＞15N/mm² |
| |
|
Packing speed(bag/minute) |
30～100Bags/min |
30～120Bags/min |
| |
|
Packing film width(mm) |
80～300mm |
80～450mm |
| |
|
Power specification |
220V 50/60Hz 2.4KVA |
220V 50/60Hz 2.4KVA |
| |
|
Machine weight(kilogram) |
800kg |
900kg |
| |
|
Overall size(L*W*H) |
3780×640×1560mm |
4400×830×1700mm |
| |
